Nilon Ball Valve are been majorly used by various industries in India & Globally. Nilon ball valves are available in regular port, full port, & multi port. Nilon ball valves are smooth machined and strait through flow area totally avoid pressure drop across the valve. Nilon has also design specialty ball valve for various projects.
| Manufacturing Standard | BS 1873 |
| Testing Standard | BS 6755 / API 598 |
| Pressure Class | 150# to 1500#, PN10 to PN16 |
| Material of Construction Cast | Cast Iron IS 210, Gr. FG 200/220/260, Cast Carbon Steel ASTM 216 Gr. WCB, Cast Steel ASTM 352,Gr.LCB & LCC Cast Stainless Steel ASTMA 351 CF8/CF3/CF8M/CF3M Alloy 20 ASTM A351 Gr. CN7M Forged Carbon Steel ASTM A 105 Duplex and Hastelloy |
| Design Type | Bolted Bonnet renewable seat O.S. & Y Type |
| Size Range | 1⁄2” Through 20” |
| End Connection | Flanged Ends, Screwed Ends to NPT/BPT & Socket Welded to ANSI B16.11 |
| Engineering Options | Lever operated, Gear operated, Electrical Actuator operated, pneumatic. |
